| Spindle Motor (kW): | 15 |
| Standard Accessories: | Fanuc Control Tool Setter Chip Conveyor Tailstock Work Light |
| Services Programme: | Installation/commissioning |
| CNC Lathe Linear Slideway: | Muli-Axis CNC Lathe Box Slideway |
| Max Swing (mm): | 450/520 |
| Max Turning Diameter (mm): | 320/380 |
| Max Turning Length (mm): | 500 |
| X Travel (mm): | 160+10~190+20 |
| Z Travel (mm): | 540 |
| Rapid Feed Rate (x/z) (m/min): | 20 |
| Chuck Size (mm): | 200 |
| No. of Tools: | 12 |
| Bar Capacity (mm): | 65 |
